SHORTRON – 2 x NC – Ø 22.3 mm – 2 x NC – Ø 22.3 mm – AgNi – Faston Terminal 2.8 x 0.8 mm – AgNi – Faston Terminal 2.8 x 0.8 mm – FRVKDOO

Discover the SHORTRON E-Stop: Engineered for resilience with 50,000 cycles, IP67 rating, and vibrant red actuation. Ensure safety with a twist!

SHORTRON – 2 x NC – Ø 22.3 mm – 2 x NC – Ø 22.3 mm – AgNi – Faston Terminal 2.8 x 0.8 mm – AgNi – Faston Terminal 2.8 x 0.8 mm – FRVKDOO

Discover the SHORTRON E-Stop: Engineered for resilience with 50,000 cycles, IP67 rating, and vibrant red actuation. Ensure safety with a twist!

Product Documents

Price

$38.21 excl. Sales Tax

Available on backorder

$38.21

Contact Equipment

2 x NC

Panel Cutout

Contact Material

AgNi

Contact Details

Release

twist right or left

Overload Protection

yes

Foolproof

No

Illumination

Yes

Labeling Option

No

Lampholder

none, with integrated 3 mm LED

IP Protection Front

IP65, IP67

Color Bezel

Yellow

Color Actuator

Red

Lifecycle

50,000 switching cycles

Certifications

CE, CSA, ROHS, UL

Mounting Depth

25 mm

Certification Standards

DIN EN ISO 13850:2016-05, EN ISO 13850:2015(D), ISO 13850:2015(E)

Product Series

Product Group

Contact Type

Faston

Enhance your safety systems with the SHORTRON Emergency Stop. This robust E-Stop is designed for reliability and durability, featuring illumination with an integrated 3 mm LED and a long-lasting lifecycle of 50,000 switching cycles.

Constructed with AgNi contact material and equipped with Faston Terminal 2.8 x 0.8 mm, it ensures a secure and rapid connection. The unit is certified with CE, CSA, ROHS, and UL standards, adhering to rigorous safety norms like DIN EN ISO 13850:2016-05.

Its IP65 and IP67 ratings guarantee protection against dust and water, making it suitable for challenging environments. The yellow bezel and red actuator enhance visibility and accessibility.

Installation is straightforward with a panel cutout of Ø 22.3 mm and a mounting depth of 25 mm. The device offers flexible release mechanisms, allowing twisting to the right or left, and includes overload protection for added safety.
